Electrical Ratings • 760 Amps • 600V per UL 1059 & CSA 22.2 No.158, class B & C requirements • Short circuit current ratings (SCCR): See SCCR section below for speci! cations. • CU7AL - 75°C connector terminal rating with copper or aluminum wire • Factory & Field Wiring
Material Information • Insulator base: • Phenolic • Flammability rating of insulator base UL94V0 • Insulator base temperature rating: -40°C to 150°C (UL RTI) • Connector: aluminum, tin plated • Terminal set screws: aluminum, tin plated • Connector mounting screws: steel, zinc plated • RoHS compliant
